ZED 2i is an IP66-rated Rolling Shutter camera built for spatial analytics and immersive experiences, powered by Neural Depth Engine 2. Ready to deploy, it has a robust aluminum enclosure, high-performance IMU and USB 3.1 connection.
Combine long-range depth perception with AI to perceive your environment in 3D with up to a 120° (Diagonal) wide-angle field of view.
Use a highly reliable USB 3.0 type-C cable with thumbscrew locking connectors and ensure a secure interconnection for your systems.
Resistant to dust, water and humidity, the ZED 2i is designed for outdoor applications and challenging medical, industrial, agricultural environments and more.
Featuring 9-DoF sensors for spatial and positional awareness. Factory calibrated on 6-axis with robotic arms.
Select a 2.1 mm or a 4 mm lens depending on your application. Add a built-in CPL polarizing filter when working outdoors.
With flexible mounting options and a flat bottom, the ZED 2i can be easily integrated in any system and environment.
Dimensions
124.5 x 30.5 x 26.5 mm (4.9 x 1.2 x 1.04’’)
Baseline
63 mm (2.4’’)
Weight
60 g (0.14 lb)
Operating Temperature
0°C to +45°C (32°F to 113°F)
Video Output
2K at 15 FPS with Output resolution side-by-side of 2x(2208x1242)
1080p at 30 or 15 FPS with Output resolution side-by-side of 2x(1920x1080)
720p at 60, 30 or 15 FPS with Output resolution side-by-side of 2x(1280x720)
WVGA at 100 FPS with Output resolution side-by-side of 2x(672x376)
Video Recording
Native resolution video encoding in H.264, H.265, Lossless formats (on host)
Video Streaming
Stream anywhere over IP
Depth Resolution
Native video resolution (in Ultra mode)
Depth FPS
Up to 100Hz
Depth Range Max
0.1m to 15m (0.3ft to 49ft)
Ideal Range
0.1m to 9m (0.3ft to 29.5ft)
Depth Technology
Stereo Depth Sensing
Motion Sensors
Accelerometer
Gyroscope
Data Rate: 800Hz
Pose Update Rate
Up to 100Hz
Motion Technology
6-DoF visual-inertial stereo SLAM with sensor fusion
Pose Drift
Translation: 1.0%
Rotation: 0.013°/m
(without loop correction)
Detection Outputs
Bounding Boxes 2D/3D
Location
Speed
Unique ID
Segmentation Masks
Skeleton Tracking
18x, 34x or 38x Body Keypoints
Object Types
Persons, Vehicles
Custom Objects
Object Tracking
Yes
Lens Type
6-elements all-glass dual lens
Aperture
ƒ/2.0
Focal Length
2.8mm (0.11’’)
Field of View
102° (H) x 57° (V) x 118° (D) max.
Polarizing Filter
None
Sensor Resolution
Dual 4M pixels sensors with large 2-micron pixels
Sensor Format
Native 16:9 format for a greater horizontal field of view
Sensor Size
1/3” backside illumination sensors with high low-light sensitivity
Shutter Sync
Electronic Synchronized Rolling Shutter
Camera Controls
Adjust Resolution, Frame rate, Brightness, Contrast, Saturation, Gamma, Sharpness, Exposure and White Balance
Connector
USB 3.0 Type-C port
Mounting Options
4x M2 thread mounts
Connectivity Power
Power via USB 5V / 380mA
